Focus Alpha-Jet A2 UV printer

Print Technology:  Micro Piezo Inkjet
Print Head:  3pcs EPSON F1080(XP600)
Head Channel:  18 channels
Head number:  3-head, White+Color+Varnish
Head protection:  Intelligent anti-scratch
Max. print size:  610mm*420
Max. printing thickness: 20
Description Specification Printing Videos Tutorial videos


See how a world-first Focus Inc new A2 UV DTF Printer transfer
on 101 different kinds of materials





      So, if you buy a UV printer for own using:





Focus Inc. Alpha-Jet X flatbed uv printer with the newest digital inkjet printing technology offers users direct-printing capabilities onto a virtually limitless choice of three-dimensional media. In addition to supplying technology for product customization, We offer a range of small and large UV printer devices. These are machines for customizing and creating unique graphics products. Capitalizing on its peerless heritage in compact UV LED direct-to-object print technology, the plus reaffirms Focus's market dominance in this rapidly developing sector. Geared to on-demand printing of the very highest quality at industrial production levels of output, Focus Alpha-Jet X UV flatbed printer utilizes state-of-the-art technology to deliver a powerful and reliable digital alternative to traditional screen print operations.




A Smart Machine for Customizing Hundreds of items

                             Using the newest LED-UV curing technology, the Alpha-Jet is a low-heat, water-cool-running machine that
                                                combines with vibrant UV inks to print on the following materials:





    Choose a Right Machine to Suit Your Budget and Your Business



FOCUS INKJET ALPHA-JET A2 SIZE UV PRINTER
Print Technology:  Micro Piezo Inkjet
Print Head:  3pcs EPSON F1080(XP600)
Head Channel:  18 channels
Head number:  3-head: White+Color+Varnish
UV system:  100-Degree adjustable
Cooling system: Water cooling
Temperature adjust:  Auto on/off. 25-35℃
UV wavelength:  395-405nm
Head protection:  Intelligent anti-scratch
Print speed:  175s/A2 size(1440*720dpi)
Print model:  Unidirection/Bidirection
Print resolution:  720*720dpi-720*3080dpi
Print type: One pass/Single/Copies
White layer:  Bottom/Top/Middle
Rip software:  FocusRIPV9.07
Image type:  Tiff, Jpeg, Png, Psd, Pdf
Repeat precision:  0.04mm
Head cleaning:  Auto flushing+Keep wet
Max. print size:  40*60cm
Print media:  Hard/Flexible/Bottle/ Tshirt
Media thickness adjust:  Software auto detection
Max. print thickness:  20cm
Ink type:  UV ink
Ink system:  Refill ink tank system
Ink process system: Auto shaking + circulation
Ink level:  Auto detection+Auto alarm
Color model:   8-color(CMYK+LC+LM+White+Varnish)
Tank volume:  500ml refillable
Color Rendition:  ICC profile+Curve
Position type:  Laser marking
Print table: Vacuum adsorption
Table treatment:  Teflon coating
Print model: 3D. Wave. Rand. Eclosion
Motion config:  Servo motor
Control interface:  Control panel+Software
Drive config:  3Pcs Linear rails+Dual Ballscrew
System require: WINXP/WIN7/WIN10 32/64bit
Working environment:  18-25℃, 50% Humidity
Working power: 120W
Electric supply:   110V/220V
Interface: USB2.0/3.0/TCPIP
Gross weight/Net weight:  230KG/150KG
Packing size: 113cm*132cm*93.5cm
Machine size:  98cm*121.5cm*67.8cm










Advantages:
1)CMYK+LC+LM+W+Varnish 8 color ink type
2)Compatible with Epson XP600 print head
3)Max. 60cm*40cm A2 printing size
4)With 3 high-power Taiwan Delta bvacuum suction fans
5)With Hiwin brand linear rail and ball screw , no noise , high speed , high resolution
6)Adopting American GMC luxury car standard insulation anti-interference wiring
7)Automatically ink wipe , maintenance system , prevent scratching and avoid printing head clog in idle time
8)Ink level sensor with light and alarm
9)Magnetic shaking setting ink the ink tank which can twirling in the bottle to avoid precipitation of white ink
10)High-sensing touch screen control button
11)Automatic detecting exactly height sensor, avoiding print head scratch
12)Stainless steel body of printer , no worry about the oxidation as ink drip on it
13)Every cable was clearly marked which is convenient for customer learning and operating
14)Stainless steel body of printer , no worry about the oxidation as ink drip on it
15)Complete acrylic cover , you couldn't find any screw or connection line on surface
etc. latest research and development results!



The UV Printing Process

UV printers use ultraviolet LED lights to dry or cure ink during the printing process. Attached to the print carriage is a UV light source that follows the print head. The LED light spectrum reacts with photo-initiators in the ink to instantly dry it so that it immediately adheres to the substrate.

With instant curing, UV printers can create photorealistic graphics on a variety of materials including items like plastic, glass and metal.

Some of the major benefits that attract businesses to UV printers are:

Environmental Safety

Unlike solvent inks, true UV inks release little to no volatile organic compounds (VOCs) which makes this printing process eco-friendly.

Faster Production Speeds

Inks cure instantly with UV printing, so there’s no downtime before finishing. The process also requires less labor and enables you to get more done in a shorter period of time than with other printing techniques.

Lower Costs

There are cost savings with UV printing because there’s often no need to use additional materials in finishing or mounting and additional protection with laminates may not be needed at all. By printing directly to the substrate, you end up using less materials, which can save you time and labor.



Online video demo:


Spot varnish flatbed uv printing



High-sensing touch screen control button



                                                                                                                                        More video...



Absolute great samples printed

Application of China Manufactory Alpha Functional Printer DX10/DX11 Digital Printing Machine

Glass, plastic, metal, leather, acrylic, wood, ceramic, PVC, ABS, stone, cardboard, paper, cylinder bottles, balls, pens, phone cases, id cards, bags, boxes, photo album, oil paintings, slipper etc.










  More printing sample...



                    Or, if you take a machine for sell:

Focus Digital Technology Co., Ltd.

was set up in Shanghai, China, which is a manufacturer to R&D the best and potential DTG printer, digital UV flatbed printer,  signs &adverting products. With 17 years experience, we have the ability to supply all products in reasonable price and real-time support lean upon our own production line, professional engineers, strict parts purchase channel and altitudinal responsible action.



Our mission:  Focus, All for customer value.
Our vision:  Focus, Ready to print.









 More about focus...



Our exhibition

Certification





Our Advantages

OUR ADVANTAGES

QUALITY ASSURANCE

To provide quality products at the same time to improve after-sales support

ONE-STOP SERVICE

We have competent R&D Group and

experienced engineers

INDEPENDENT FACTOR

We have own assem- bling factory, ensure every part of the product perfect

PROFESSIONAL TEAM

Professional team to provide you with efficient service













Customers payment shows

It's so appreciated that we have gained numerous customers trust from all over the world, which is the impetus for us to do better in the next 10 year and lots of another ten years.





Packaging details

Packing of FOCUS INKJET ALPHA-JET X A2 SIZE UV PRINTER




With years of export experience along with excellent quality, advanced services and competitive prices, we have won numerous customers' trust and support.

                                          FOCUS INKJET ALPHA-JET X A2 SIZE UV PRINTER
Print Technology:  Micro Piezo Inkjet
Print Head:  EPSON F1080
Head Channel:  18 channels
Head number:  3-head: White+Color+Varnish
UV system:  100-Degree adjustable
Cooling system: Water cooling
Temperature adjust:  Auto on/off. 25-35
UV wavelength:  395-405nm
Head protection:  Intelligent anti-scratch
Print speed:  175s/A2 size(1440*720dpi)
Print model:  Unidirection/Bidirction
Print resolution:  720*720dpi-720*3080dpi
Print type: One pass/Single/Copies
White layer:  Bottom/Top/Middle
Rip software:  RIPRINT
Image type:  Tiff, Jpeg, Png, Psd,Pdf
Repeat precision:  0.04mm
Head cleaning:  Auto flushing+Keep wet
Max. print size:  40*60cm
Print media:  Hard/Flexible substrates/Bottle
Media thickness adjust:  Software auto detection
Max. print thickness:  20cm
Ink type:  UV ink
Ink system:  Refill ink tank system
Ink process system: Auto shaking + circulation
Ink level:  Auto detection+Auto alarm
Color model:   8-color(CMYK+LC+LM+White+Varnish)
Tank volume:  500ml refillable
Color Rendition:  ICC profile+Curve
Position type:  Laser marking
Print table: Vacuum adsorption
Table treatment:  Teflon coating
Print model: 3D. Wave. Rand. Eclosion
Motion config:  Servo motor
Control interface:  Control panel+Software
Drive config:  3Pcs Linear rails+Dual Ballscrew
System require: WINXP/WIN7/WIN10 32/64bit
Working environment:  18-25, 50% Humidity
Working power: 120W
Electric supply:   110V/220V
Interface: USB2.0/3.0/TCPIP
Gross weight/Net weight:  150KG/230KG
Packing size: 113m*132cm*93.5cm
Machine size:  98cm*121.5cm*67.8cm
