Focus Inc. Athena Jet Plus Industrial DTG Printer

Print Technology:  Micro Piezo Inkjet
Print Head:  2pcs 4720 print head
Head Channel:  16 channels
Head number:  2-head, White and color on one pass printing
Head protection:  Intelligent anti-scratch
Max. print size:  610*420mm
Description Specification Printing Videos Tutorial videos

Focus Athena Jet DTG printer with newest T SHIRT VERSION Rip printing



There you are, my friend

My name is Athena-Jet Plus

I'm also called direct to garment printer(DTG)

You must be curious about my appearance, my configuration, my functions, my value, right?




My outlook



Designed by my owner, Focus Inc I'm newest digital inkjet printing technology offers users direct-printing capabilities onto a virtually limitless choice of three-dimensional media. In addition to supplying technology for product customization, We offer a range of small and large dtg printer devices. These are machines for customizing and creating unique graphics products. Capitalizing on its peerless heritage in compact DTG direct- to-object print technology, the plus reaffirms Focus market dominance in this rapidly developing sector. Geared to on-demand printing of the very highest quality at industrial production levels of output, Focus Athena Jet Plus Industrial DTG printer utilizes state-of-the-art technology to deliver a powerful and reliable digital alternative to traditional screen print operations.







My Specification



                                FOCUS INKJET ATHENA JET PLUS Industrial DTG PRINTER

Print Technology:  Micro Piezo Inkjet

Print Head:  NEW 4720 Print Head

Head Channel:  16 channels

Head number:  2 heads: White and color on one pass printing

Head protection:  Intelligent anti-scratch

Print speed:  175s/A2 size(1440*720dpi)

Print model:  Unidirection/Bidirction

Print resolution:  1440*1440dpi-1440*2880dpi

Rip software:  FocusRIPV9.07/Wasatch/Ripprint

Image type:  Tiff, Jpeg, Png, Psd,Pdf

Repeat precision:  0.04mm

Head cleaning:  Auto flushing+Keep wet

Max. print size:  40*60cm

Print media: Tshirt,hoodie,canva,hats,socks,shoes

Media thickness adjust:  Software auto detection

Max. print thickness:  20cm

Ink type:  Textile ink

Ink system:  Refill ink tank system

Ink process system: Auto shaking + circulation

Ink level:  Auto detection+Auto alarm

Color model:   CMYK+White

Tank volume:  500ml refillable

Color Rendition:  ICC profile+Curve

Position type:  Flatbed, pallet

Control interface:  Control panel+Software

Drive config:  4Pcs Linear rails+Dual Ballscrew

System require: WINXP/WIN7/WIN10 32/64bit

Working environment:  18-25℃, 50% Humidity

Working power: 120W

Electric supply:   110V/220V

Interface: USB2.0/3.0/TCPIP

Gross weight/Net weight:  150KG/260KG

Packing size: 98cm*68cm*88cm

Machine size:  133cm*113cm*98cm







My Advantages

1)CMYK+W color ink type
2)Compatible with Epson 4720 print head
3)Max. 60cm*40cm A2 printing size
4)With white ink circulation system prevent white ink from blocking print head
5)With Hiwin brand linear rail and ball screw, no noise, high speed, high resolution
6)Adopting American GMC luxury car standard insulation anti-interference wiring
7)Automatically ink wipe, maintenance system, prevent scratching and avoid printing head clog in idle time
8)Ink level sensor with light and alarm
9)Magnetic shaking setting ink the ink tank which can be twirling in the bottle to avoid precipitation of white ink
10)High-sensing touch screen control button
11)Automatic detecting exactly height sensor, avoiding print head scratch
12)The stainless steel body of the printer , no worry about the oxidation as ink drip on it
13)Every cable was clearly marked which is convenient for customer learning and operating
14)The stainless steel body of the printer , no worry about the oxidation as ink drip on it
15)Complete acrylic cover, you couldn't find any screw or connection line on the surface
etc. latest research and development results!


My feature



1.With two Epson 4720 print heads (Micro piezo technology), 2.5pl-5pl varlable ink droplet printing


2.White and color print in single time. Athena-Jet Plus support to print white ink and ink color pring by one pass , which can save much time for print dark/black fabric and increase the output


3.Different shirt Pallet 200X200MM / 305X405MM / 405X505MM / 405X605MM Easy changing system to ensure the requirements of print slze of fabric


4.With white ink circulation system prevent white head from blocking



5.
With new technology cap station system for print head cleaning  and keep wet, prevent print heads from blocking.


6. With newest and unique design of ink stack lifting technology, ensure stable operation and improve printing accuracy


Absolute great samples I printed








Or, if you take me to sell:

Focus Digital Technology Co., Ltd.was set up in Shanghai, China, which is a manufacturer to R&D the best and potential DTG printer, digital UV flatbed printer,  signs &adverting products. With 17 years of experience, we have the ability to supply all products in reasonable price and real-time support lean upon our own production line, professional engineers, strict parts purchase channel, and altitudinal responsible action.







My Package










With years of export experience along with excellent quality, advanced services and competitive prices, we have won numerous customers' trust and support.

1.Every printer we delivered need to pass our second inspection before delivery.

2.International standard wooden package.

3.Our shipping forwarder could help you to deal with the custom clearance.







With years of export experience along with excellent quality, advanced services and competitive prices, we have won numerous customers' trust and support.

1.Every printer we delivered need to pass our second inspection before delivery.

2.International standard wooden package for China Manufactory galaxy ecosolvent printer dx5 digital printing machine.

3.Our shipping forwarder could help you to deal with the custom clearance.


About our team




Other article:
1.《10 basic knowledge you need to know about DTG printers
2. 《What knowledge does a photographer need to know for DTG printing?
3.《What is DTG printer?
4.《How to buy a digital printer from China?》
5. 《Ten pitfalls of buying digital DTG printers in china.》
6. 《How to start a business by a DTG printer?》
7. 《How to maintain a print head during holiday?》
.....


Please visit Focus UV printing forum for more articles

                                FOCUS INKJET ATHENA JET PLUS Industrial DTG PRINTER

Print Technology:  Micro Piezo Inkjet

Print Head:  NEW 4720 Print Head

Head Channel:  16 channels

Head number:  2 heads- White and color on one pass printing

Head protection:  Intelligent anti-scratch

Print speed:  175s/A2 size(1440*720dpi)

Print model:  Unidirection/Bidirction

Print resolution:  1440*1440dpi-1440*2880dpi

Rip software:  FocusRIPV9.07/Wasatch/RiPrint

Image type:  Tiff, Jpeg, Png, Psd, Pdf

Repeat precision:  0.04mm

Head cleaning:  Auto flushing+Keep wet

Max. print size:  40*60cm

Print media: Tshirt,hoodie,canva,hats,socks,shoes

Media thickness adjust:  Software auto-detection

Max. print thickness:  20cm

Ink type:  Textile ink

Ink system:  Refill ink tank system

Ink process system: Auto shaking + circulation system

Ink level:  Auto detection+Auto alarm

Color model:   CMYK+White

Tank volume:  500ml refillable

Color Rendition:  ICC profile+Curve

Position type:  Flatbed, pallet

Control interface:  Control panel+Software

Drive config:  4Pcs Linear rails+Dual Ballscrew

System requires: WINXP/WIN7/WIN10 32/64bit

Working environment:  18-25℃, 50% Humidity

Working power: 120W

Electric supply:   110V/220V

Interface: USB2.0/3.0/TCPIP

Gross weight/Net weight:  150KG/260KG

Packing size:  135cm*113cm*96cm

Machine size: 98cm*121.5cm*67.8cm


      FOCUS INKJET ATHENA JET PLUS Industrial DTG PRINTER
